THE BMW M5 TOURING E34.

The forefather of all BMW M Touring models.

The BMW M5 Touring E34. The forefather of all BMW M Touring models.

15. Sep 2021

A superlative sportscar, packed in a sporty, but never showy bodywork – that’s how BMW M described the first BMW M5 Touring in 1992. And despite the apposite, almost modest description, the high-performance vehicle was in many ways remarkable. The BMW M5 Touring E34 had not only the role of the Touring pioneer, it was also the first BMW M automobile ever to have a practical hatchback. With the inline-6-cylinder engine, originally developed for the BMW M1 super sportscar, the M suspension and an enhanced braking system, it offered power and driving pleasure beyond anything else in its class.

01 First Touring model from BMW M
02 Inline-6-cylinder engine with high-rev concept
03 Displacement: 3,795 cm³
04 Max. output: 250 kW (340 hp)
05 To a large extent hand-finished

DRIVING AND LEISURE PLEASURE.

High-performance made in Garching.

The BMW M5 Touring E34 represented a unique combination of elegant sedan, leisure vehicle and M typical sports car. The developers’ aim was to combine the characteristics of a touring model which had a highly variable loading space with the maximum sportiness of an M automobile. The race-based technology of the BMW M5 Sedan was transferred with minimal adjustments to the M5 Touring. What sounds like a modest outlay in times of fully automated production techniques, was in fact in the early 1990s a challenge – there was no production line for the high-performance Touring. The vehicle was thus assembled at BMW M in Garching near Munich. And to a great extent by hand .

Straight from motorsport: the S38B38 engine with single throttle valves.

WITH THE LICENCE TO THRILL.

The engine came from the BMW M1.

At the centre of the concept for the second BMW M5 in the mid-1980s stood the further development of the legendary four-valve six-cylinder engine from the BMW M1. This originally 3.5-litre engine with two overhead camshafts and intake-manifold fuel injection supplied the 1978 sports car with 204 kW (277 hp), before achieving 210 kW (286 hp) in the BMW M635 CSi and BMW M5 of the first generation. To further boost performance, the BMW M5 E34 Touring piston stroke and bore were increased, which in turn increased combustion chamber capacity to 3,795 cc. The S38B38 engine was born. With this and other technical details – for example the resonance plenum – from 1992, the engine offered a proud 340 hp at 6,900 rpm and 400 Nm torque at as low as 4,750 rpm. Even today, this is excellent for a six-cylinder engine of this class. With this version, which was used in the facelift of the BMW M5 Sedan too, the S38 also reached the end of its development.

5.9 sec.

is how long the BMW M5 Touring E34 took to sprint from 0 to 100 km/h. From 250 km/h upwards it was electronically limited.

Former advertisement for the BMW M5.

TANGIBLE MOTORSPORT DNA.

Compound braking system and 6-speed transmission from 1994.

The final stage of the BMW M5 Touring E34 as an overall vehicle wasn’t achieved until mid-1994. The last model contained several technical innovations which in particular favoured the M automobile’s performance. As the engine had been, now the braking system too was heavily influenced by motorsport: The compound braking system with radial plain bearings for the brake disc friction ring was at that point unique in series car production. Thanks to the thermal benefits, the system offered better brake performance, less weight and a longer life – even under heavy pressure.

The newly developed compound braking system for the BMW M5 and BMW M5 Touring.

Recognisable by the widened BMW kidney: the final facelift of the BMW M5 Touring.

Another innovation was the 6-speed transmission, with the new extra gear serving as an additional driving gear. In addition, the especially altered adaptive suspension was also standard. The top model in the final configuration could be recognized on account of its new 18-inch light-alloy rims with open five-spoke design and the wider front apron with redesigned kidneys.

Driver-oriented central console and M steering wheel: the interior of the BMW M5 Touring.

GENTLEMEN SPORT.

The Touring’s noble interior.

Superb leather upholstery, an M sports steering wheel and a driver-oriented central console characterized the interior of the BMW M5 Touring. The on-board computer and clearly designed instruments in the speedometer panel were top-notch for the time.

Driver-oriented central console and M steering wheel: the interior of the BMW M5 Touring.

< 1000

Only 891 specimens of the BMW M5 Touring left the factory at Garching between 1992 and 1995. Thus, this M automobile is one of the rarest examples of the marque.

EXOTIC STATUS.

The BMW M5 Touring E34 is very rare.

The first BMW M5 Touring filled a niche which was especially small at the start of the 1990s. The production figure of just 891 vehicles underlines this – the model has a rare exoticism in the history of BMW M. But the concept, the technology, which came from racing, and the brilliant execution by the M engineers were ground-breaking.

Never say never: For the first time in history, there will be a BMW M3 Touring. The connection between M specific peak performance and the intelligent functionality of a Touring model make the BMW M3 G81 a very special vehicle.
