BMW M4 Competition Coupé

The M Drift Analyser.

Episode 23: BMW M3 and M4 Explained.

The M Drift Analyser.Episode 23: BMW M3 and M4 Explained.
08. Jul 2021

The epitome of racing feeling in everyday traffic starts a new round. 35 years after the debut of the first BMW M3, BMW M GmbH presents the latest generation of its high-performance automobiles in the premium mid-size segment. Time to introduce the two new vehicles. In the #M3M4explained series, the developers have the floor.

BMW M developer Thomas likes to look at the world from the side window: The engineer is responsible for the M Drift Analyser, which is being offered for the first time in the BMW M3 and M4 models. The tool can be used to evaluate individual drifts or entire drift sessions - for even more driving fun. In the video, Thomas explains how to use the system. In our Q&A, he answers the community's questions

BMW M4 Competition Coupé:
Fuel consumption in l/100 km (combined): 9.6-9.8 (WLTP)
CO2 emissions in g/km (combined): 219-224 (WLTP)

Read more
BMW M3 M4 Explained

BMW M ENTHUSIASTS ASK, BMW M EXPERTS ANSWER.

Is there any difference in drift behaviour between M3 and M4, or are they the same?



In principal, both models are very close in their technical setup and dimensions, weight etc. Hence no difference in drift behaviour.



Can I use this on my X5 M Competition, or can I only use the Track Mode and Laptimer?



The M Drift Analyser and 10-stage traction control are currently available for the new generation BMW M3 and M4 only. For the other models, only Track Mode and M Laptimer are available.



Does the Drift Analyser come with every M3 and M4?



It is available for all new BMW M3 / M4 / M3 Competition / M4 Competition models as part of the M Drive Professional option.



Is the Drift Analyser available on the manual transmission models?



Yes, of course.

Read more
BMW M3 Competition

So, does it affect the Drift Analyser if u were to put drift tires on it with the traction control activated?

No, as the geometric and acceleration parameters that are monitored do not change within the analysis. However, changing the tire or changing road surfaces may require a driver's adjustment to the M Traction Control level.

What is the angle limit for this mode?

There is no limitation for the drift angle. And it is not a controlled drift mode. The driver has to react properly at any time … if you spin, it might by as high as 360° or even more. The maximum drift angle for RWD mode is limited by the maximum steering angle - approximately 35°.

Read more

Can it be used during break in period already?

That is technically possible. Still, with regards to all mechanical components involved it is not recommended for use during break in.

Does level 10 in the traction control prevent the car from spinning and drifting at all?

No. M Traction Control is a subfunction available in DSC OFF only. The stability control is switched off completely - no brake interventions at all!

When does it make sense to drive with traction control on 10? Is it like MDM?

Level 10 is designed as a traction optimized assist for UHP tires on slippery conditions like a wet road / racetrack. For drifting, a lower level like 6 and below is recommended - depending on the grip conditions of course. Please, take a look at Episode 17 for more details on the M Traction Control.

How does the system detect the type of road surface?

The system constantly monitors parameters like yaw rate, wheel spin, steering angle and even tire temperatures.

Were any sensors added to facilitate the Drift Analyser?

No.

Read more
BMW M4 Competition Coupé

Does the M Drift Analyser also work on ice and snow?

Yes, of course.

Does the Drift Analyser recognize alternating curves while drifting?

Sure it does. It will give you an even higher scoring for manouveres like that!

What does the throttle icon shown in the headup display mean?

This indicates way too much overpowering of the accelerator pedal when M Traction Control and the M Drift Analyser are active. This also depends on the selected level of M Traction Control.

Read more
BMW M4 Competition Coupé

What is the trophy icon for?

Well done! You have achieved a new high score.

What's the difference between the star rating and drift performance?

The star rating is based on the presented parameters "duration", "length" and "average angle" of the drift and some magic dust. The higher the values, the better the rating. It is renewed with every single drift. The drift performance is the "Schwimmwinkelbetragsintegral" over all drifts within a single drift session.

Can I look at the drifts afterwards?

Yes, if the Laptimer recording was active all the time you can analyse your drifts on your smartphone later. You can also share the laptimer session including the drift data with your friends using the export function within the App.

Read more
BMW M3 Competition Coupé

Which car in the BMW fleet current or previous is your favorite to drift?

I like drifting the M2 very much and the new M3/M4 is great fun either.

Have you ever done a 5-star drift?

Sure! That was an essential and entertaining part of the development.

What's the best drift score you ever got?

I am still working on my 6-star rating …



Read more
BMW M3 Competition

HOW TO USE THE M DRIFT ANALYSER.

With M Drive Professional – a standard feature in the BMW M3 Competition and BMW M4 Competition and optional available in the BMW M3 and M4 – the BMW M Drift Analyser is part of the M automobile’s operating system. When activated, it automatically records all drifts performed, then analyses and evaluates them. In this video, we explain how to use the system optimally.

Read more

1.

BMW M3 Competition

Deactivate the Dynamic Stability Control DSC. To do this, press the key beside the gear lever for at least four seconds.

2.

M Drift Analyser

Now you can select the M Drift Analyser in the central information display. Then confirm the relevant legal disclaimer to continue.

3.

M Drift Analyser

When the M Drift Analyser is displayed, the system is automatically active. In the right-hand menu bar, the steps of the M traction control and the desired mode for recording (single drift or drift session) can be selected. Now you can press "Start Drift Session" and you are ready to go.

M Drift Analyser

Need a short break? You can also deactivate the M Drift Analyser at any time in this menu – which in turn automatically reactivates the DSC.



Enjoy your drifts!
