BMW M 1000 R.

The new supersport M roadster.

BMW M 1000 R.The new supersport M roadster.

24. Oct 2022

Highest demands on both country road and the race track: The new BMW M 1000 R – M R for short – is the second M model from BMW Motorrad to celebrate its world premiere, following the M 1000 RR superbike: The M Roadster. In the anniversary year of the 50th birthday of BMW M GmbH, BMW Motorrad is also adhering to the dynamic philosophy of the most powerful letter in the world with the new M R.

01 Powerful M R 4-cylinder based on the RR engine
02 Max. output 154 kW (210 hp) at 13,750 rpm
03 0 to 100 km/h in 3.2 seconds
04 M winglets and M brakes
05 Optional M Competition package

199 kg

is the DIN empty weight of the M 1000 R – ready to ride and fully fuelled.

MORE POWER, MORE RIDING PLEASURE.

The new M R uses a modified, water-cooled four-cylinder in-line engine based on the power unit of the S 1000 RR. Its peak power output is 154 kW (210 hp) at 13,750 rpm, 33 kW (45 hp) more than in the S 1000 R. The maximum torque of 113 Nm is reached at 11,000 rpm. The maximum speed of the M R is 14,600 rpm. Increased rear wheel traction in all gears is also provided by a shorter secondary gear ratio due to the use of a sprocket with now 47 teeth (the S 1000 R has 45 teeth). In addition, the gear ratios of the fourth, fifth and sixth gears are shorter, which also benefits the rear wheel traction.

M WINGLETS.

M BRAKES.

M DESIGN.

M WINGLETS.

In addition to drive and suspension technology, aerodynamics was also a key item in the specifications for developing the M R. The new M R was given winglets in the area of the front side panels with the aim of achieving even faster lap times on the racetrack and the best possible riding stability at high speeds, Already at a speed of 160 km/h, they provide an increase in front wheel load of 11 kg at 220 km/h thanks to the aerodynamic downforce generated.

M BRAKES.

After the M 1000 RR, the new M R is the second BMW motorcycle to feature an M brake. It was developed directly using the experience gained with the racing brakes on BMW Motorrad factory racing machines in the Superbike World Championship. Together with two 320 mm brake discs of 5 mm thickness and black anodised aluminium brake disc carriers, the brake system equipped with a new radial hand brake pump currently marks the pinnacle of brake development in the field of road-legal systems. The new M R is already equipped with very lightweight forged aluminium wheels as standard.

M DESIGN.

The proportions of the M R are ultra-compact and powerful, and the three-dimensionally designed surfaces are both exciting and dynamic. Slim, slender and extremely aggressive, the M R looks extremely distinctive from the front with its new M winglets. In addition, the signature light makes the new M R clearly recognisable as a BMW from the front - analogous to the kidney grille on BMW M automobiles. The performance-oriented look of the new M R is also reflected in its colour concept. Lightwhite non-metallic / M Motorsport makes the basic variant of the M R look particularly light, sporty and rider-friendly, while the Blackstorm metallic/M Motorsport colour scheme included in the M Competition package stands for sheer power and dynamism.

BMW M 1000 R with M Competition package.

THE M COMPETITION PACKAGE.

Uncompromising design and technology.

Get ready for the race track: If the new M 1000 R in standard trim is still not enough for you, the M Competition Package offers a fascinating mix of refined components for the racing technology gourmet and the aesthetically minded rider alike. In addition to the Blackstorm metallic/M Motorsport colour scheme, the M Competition package includes M Carbon wheels, M rider footrest system, M Carbon parts such as rear wheel cover and chain guard, front wheel cover, tank covers, airbox cover with tapes, wind deflector, sprocket cover, the M pillion package as well as the M pillion cover and a milled, fully adjustable M rider footrest system.

ALL DETAILS AT A GLANCE.

The BMW M 1000 R.
• M RR shift cam engine, output 154 kW (210 hp) at 13,750 rpm and thus 33 kW (45 hp) more than in the S 1000 R. Maximum torque of 113 Nm at 11,000 rpm (S 1000 R: 114 Nm at 9,250 rpm)
• Shorter secondary gear ratio (sprocket with 47 teeth instead of 45)
• Shorter gear ratios of 4th, 5th and 6th gear
• Optimised intake system with variable intake funnels for improved charge exchange at high engine speeds
• Titanium rear silencer
• M Endurance chain
• Riding modes "Rain", "Road", "Dynamic", "Race" and "Race Pro1-3" as well as the latest generation of Dynamic Traction Control DTC and DTC wheelie function with 6-axis sensor box
• Three adjustable throttle characteristics available now for optimum response. "Engine Brake" with triple adjustability of engine drag torque in "Race Pro" mode.
• Brake Slide Assist assists the rider when brake drifting
• Shift Assistant Pro for fast upshifts and downshifts without using the clutch. Easy reversibility of the shifting scheme for racetrack use.
• Launch Control for perfect race starts and Pit Lane Limiter for keeping to the given speed precisely in the pit lane
• Hill Start Control Pro for comfortably starting off on inclines
• M winglets and wind deflectors: Brake later and accelerate earlier, plus more high-speed stability thanks to aerodynamic downforce
• Engine spoiler
• Upside-down fork in "All black" design with adjustable spring base in conjunction with standard DDC
• M brakes on a Dynamic Roadster from BMW Motorrad for the first time: The M R offers maximum braking performance for country roads and race tracks
• Aluminium forged wheels
• M Carbon wheels with M‑tapes and M‑lettering on the rim: High-grade high-tech components deliver maximum performance as part of the M Competition Package
• M handbrake and clutch lever
• Adjustable steering damper
• Milled-over handlebar clamp
• Compared to the S 1000 R, wider tubular handlebars with laser-etched "BMW M 1000 R" lettering.
• Handlebar end mirrors
• Main headlamp with illuminated M logo
• Small number plate holder
• Instrument cluster with large, perfectly readable 6.5-inch TFT display, start-up animation with M logo and OBD interface for M GPS Datalogger and M GPS Laptrigger that can be used via activation code
• Rev counter (red area) displayed in a new desig
• Lightweight M battery, rear USB charging socket, powerful LED light units, electronic cruise control and heated grips
• Keyless Ride Light (ignition only)
• M Design and dynamic design language signal ultimate roadster performance
• M Competition Package
• RDC as standard
• Extensive range of optional accessories

THE BMW M 1000 RR.

Built for racing.

With the further development of the BMW M 1000 RR, BMW Motorrad is setting a new milestone in the field of superbikes homologated for racing. Optimized aerodynamics and lightweight materials resulting in a higher top speed.
